Description
TRB142 comes with a widely used RS232 interface for remote device management.
It is equipped with mission-critical LTE Cat 1 capabilities and software based on OpenWRT, hence offering a high degree of customization.
Just like the other TRB series products, it provides a wide range of software features such as SMS control, VPN, IPsec, Firewall, and FOTA support.
This gateway is durable, offers a wide range of power supply voltages, and is compatible with Teltonika Networks Remote Management System (RMS).
Key features
CONNECTIVITY - 4G/LTE (Cat 1), 3G, 2G
SERIAL PORT - Equipped with RS232 for serial communication
COMPACTNESS - Small size, easy installation
DURABILITY - Rugged aluminum housing
9-30V - Wide range of supported power supply voltages
RMS - Compatible with Teltonika Remote Management System
Hardware
Mobile: 4G/LTE (Cat 1), 3G, 2G
CPU: Qualcomm, ARM Cortex A7, 1.2 GHz
Memory: 512 MBytes Flash (70 MBytes for userspace), 128 MBytes RAM (50 MBytes for userspace)
Powering option: 4 pin power socket, 9-30 VDC
SIM: 1 x Internal SIM holder (2FF)
Antenna connectors: 1 x SMA for mobile
Inputs/Outputs: On 4 pin socket: 2 x Digital input/Digital open collector output (configurable)
Serial: 1 x RS232
Other: 1 x Micro USB slave
Status LEDs: 3 x Connection type, 5 x Signal strength, 1 x Power
Operating temperature: -40° C to 75° C
Housing: Aluminium housing with DIN rail mounting option
Dimensions (W x H x D): 75 x 25 x 65 mm
Weight: 135 g
Software
Operating system: RutOS
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
Monitoring and Management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT
Serial: Console, Over IP, Modem, NTRIP, Modbus
Standard package contains
TRB142
5 W PSU
1 x LTE antenna (magnetic mount, SMA male, 3 m cable)
Micro-USB cable (0.8 m)
1 x hex key
QSG (Quick Start Guide)
RMS flyer
Packaging box
