Description

This small industrial LTE Cat 1 gateway is equipped with a micro USB and various Input/Output options, including Digital, Relay, Analog, and Isolated.

Paired with secure and functional RutOS, plenty of processing power, and Teltonika Networks Remote Management System (RMS), this device offers unprecedented application flexibility to manage and control equipment remotely over LTE Cat 1.

It has a wide range of software features such as SMS control, VPN, IPsec, Firewall, and FOTA support.

Perfect for application scenarios, where devices must be remotely managed using Inputs/Outputs.

Key features

• CONNECTIVITY - 4G/LTE (Cat 1), 3G, 2G
• I/O - Wide range of multiple Inputs/Outputs for remote monitoring and control
• COMPACTNESS - Small size, easy installation
• DURABILITY - Rugged aluminum housing
• 9-30V - Wide range of supported power supply voltages
• RMS - Compatible with Teltonika Remote Management System

Hardware

• Mobile: 4G/LTE (Cat 1), 3G, 2G
• CPU: Qualcomm, ARM Cortex A7, 1.2 GHz
• Memory: 512 MBytes Flash (70 MBytes for userspace), 128 MBytes RAM (50 MBytes for userspace)
• Powering option: 4 pin power socket, 9-30 VDC
• SIM: 1 x Internal SIM holder (2FF)
• Antenna connectors: 1 x SMA for mobile
• Inputs/Outputs:
  • On 4 pin socket: 2 x Digital input/Digital open collector output (configurable)
  • On 16 pin socket: 1 x Isolated input, 1 x Single wire input, 1 x Analog input (with 4-20mA capability), 1 x Latching relay output, 1 x Non-latching relay output, 2 x Dry/Wet input (configurable)
• Other: 1 x Micro USB slave
• Status LEDs: 3 x Connection type, 5 x Signal strength, 1 x Power
• Operating temperature: -40 °C to 75 °C
• Housing: Aluminium housing with DIN rail mounting option
• Dimensions (W x H x D): 75 x 25 x 65 mm
• Weight: 136 g

Software

• Operating system: RutOS
• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
• VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP
• Monitoring and Management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
• Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• Services: DDNS, VRRP, WEB filter, UPNP, Traffic Logging

Standard package contains

• TRB141
• 4.5 W PSU
• 1 x LTE antenna (magnetic mount, SMA male, 3 m cable)
• Micro-USB cable (0.8 m)
• 1 x hex key
• I/O connector
• QSG (Quick Start Guide)
• RMS Flyer
• Packaging box
