Description
This router represents our extensive industrial IoT experience brought straight to your home.
With 4G LTE-Advanced technology you can use TCR100 as a primary or a backup connectivity source.
Two Ethernet interfaces and Dual-band Wi-Fi allow to connect multiple devices with ease!
TCR100 features connectivity indicators, Wi-Fi, and Wi-Fi Protected buttons for quick and simple setup.
Reliable, secure and easy to use – TCR100 is the perfect choice for any home network.
Key features
- 4G LTE-Advanced - LTE CAT6 enables cellular speeds up to 300Mbps with carrier aggregation
- Wi-Fi - Dual-Band with 2.4 GHz & 5.0 GHz frequencies
- DURABLE - Rugged housing with heatsink for thermal efficiency
- SECURE - Firewall and numerous VPN services including OpenVPN, IPsec, PPTP, L2TP & DMVPN
- RMS - Compatible with our RMS enabling remote access and on-demand VPN services
- RutOS - Powerful OS with intuitive UI based on OpenWrt empowers endless configuration possibilities.
Hardware
- Mobile: 4G (LTE) – Cat 6; DC-HSDPA; HSUPA; WCDMA
- CPU: CPU Qualcom MIPS 24Kc; 650 MHz
- Memory: 128 MB, DDR2 RAM
- Storage: 16 MB, SPI Flash
- Ethernet: 2 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 1 x LAN
- Power supply: 9 – 30 VDC, 4 pin DC connector
- Connectors: 1 x 4 pin DC, 2 x Ethernet, 2 x Mobile SMA
- SIM: 1 x external SIM holder
- Status LEDs: 1 x WAN status, 1 x Wi-Fi status, 3 x connection strength, 2 x LAN status
- Operating temperature: -40 °C to 75 °C
- Housing: Plastic housing with aluminum screws and heatsink
- Dimensions: 150 mm x 37 mm x 105 mm
- Buttons: Wi-Fi On/Off, Activate WPS, Reset
- Wireless: Dual-band Wi-Fi (2.4 GHz and 5 GHz)
Software
- Operating system: RutOS (OpenWrt based Linux OS)
- Multiple PDN: Possibility to use different PDNs for multiple network access and services
- Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet, SNMP
- Networking features: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPsec
- Unique networking features: VLAN, Load balancing, Mobile quota control, WEB Filter, Network Backup, Auto Failover
- Connection monitoring: Ping Reboot, Periodic Reboot, Wget Reboot, LCP and ICMP for link inspection
- Authetication: Pre-shared key, digital certificates, X.509 certificates
- Keep settings: Update FW without losing current configuration
- Monitoring & Management: WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS
- Supported languages: Busybox shell, Lua, C, C++
- Development tools: SDK package with build environment provided
Standard package contains
- Router TCR100
- 18 W PSU
- 2 x LTE antennas (swivel, SMA male)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box
