The Teltonika TAP400 is designed to provide a stable and strong wireless network for small and medium-sized businesses. The access point is suitable for environments where network load varies and client devices move between access points. Wi-Fi 6 technology, MU-MIMO and a 2.5 GbE uplink enable high data transfer speeds and better capacity for many simultaneous connections.

The access point supports wireless mesh networking and 802.11r-based fast roaming, which makes it easier to expand the network and improves the user experience in mobile applications. Management, monitoring and software updates can be performed remotely via Teltonika RMS or the device's own web interface.

Features

• Wireless technology: Wi-Fi 6 (802.11 b/g/n/ac/ax), dual band
• Data transfer rate: up to 2402 Mbps (5 GHz), up to 576 Mbps (2.4 GHz)
• Concurrent users: up to 512
• Wireless features: mesh (802.11s), fast roaming (802.11r), 802.11k/v
• Ethernet: 1 × RJ45, 10/100/1000/2500 Mbps
• Power supply: 802.3af PoE, power consumption < 11 W
• Management: Web UI, SSH, Teltonika RMS, JSON-RPC API
• Processor: MediaTek Dual-Core 1.3 GHz
• Memory: 512 MB DDR3, 16 MB NOR + 512 MB NAND Flash
• OS: RutOS (OpenWrt based Linux OS)
• Dimensions: Ø 158 × 31.4 mm, weight 285 g
• Mounting: ceiling mount (bracket included)
• Security: WPA2- and WPA3-Enterprise/PSK, 802.11w, MAC filtering
  • Authentication: SSH key-based login, HTTPS, CLI support, blocking of IPs and login attempts, time-based login blocking and generation of random passwords
  • VLAN: tag-based VLAN separation
  • Access control: separate and flexible access management for SSH, Web, CLI and Telnet connections
  • Certificate management: built-in certificate management tool (CA, server, client, Let’s Encrypt and SCEP certificates)
  • 802.1X: port-based network access control (client)

Package contents

• 1 x TAP400 access point
• 1 x Quick guide

Links

Manufacturer product page

User manual page
