Description

RUTX50 is a future-proof, multi-network industrial router that provides 5G mobile connectivity for fast, data-rich applications. 5G dual SIM mobile communication combined with a 5 Gigabit Ethernet port and dual-band Wi-Fi enables reliable, ultra-low latency data transfer. The power of 5G technology together with a wide range of interfaces and industrial hardware features ensures adaptability for future upgrades and expansions. RUTX50 is shipped with the RutOS operating system, which provides advanced security features and specialized industrial protocols for a wide range of professional applications, and it is compatible with our remote management system (RMS), optimizing remote management and monitoring capabilities for large device fleets.

Key features

• 5G - Extremely high mobile speeds up to 3.3 Gbps
• DUAL SIM - Uninterrupted communication with automatic failover
• SA & NSA - Supports both architectures to leverage 5G infrastructure
• WIFI 5 - Dual-band throughput for up to 150 clients simultaneously
• ULTRA-LOW LATENCY - Single-digit latencies for critical applications
• FUTURE-PROOFING - Backward compatible with 4G (LTE CAT 20) and 3G network technologies

Hardware

• Mobile 5G: Sub-6Ghz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2)
• Mobile 4G: LTE Cat 20 2.0Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL
• CPU: Quad-core ARM Cortex A7, 717 MHz
• Flash memory: 256 MB
• RAM: 256 MB
• Power options: 4-pin power connector, 9-50 VDC
• SIM: 2 x SIM slots (Mini SIM – 2FF), 1.8V/3V
• Antenna connectors: 4 x SMA for mobile, 2 x RP-SMA for WiFi, 1 x SMA for GNSS
• Ethernet: 5 x 10/100/1000 Ethernet ports: 1 x WAN (configurable as LAN), 4 x LAN
• WiFi: 802.11b/g/n/ac Wave 2 (WiFi 5) with data rates up to 867 Mbps (dual-band, MU-MIMO), 802.11r fast roaming, Access Point (AP), Station (STA)
• Wireless mesh/roaming: Wireless mesh (802.11s), fast roaming (802.11r)
• GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
• Inputs/Outputs: In the 4-pin connector: 1 x Digital input, 1 x Digital open-collector output
• Other: 1 x USB-host, 1 x Grounding screw
• Status LEDs: 3 x connection status LEDs, 3 x connection strength LEDs, 10 x Ethernet port status LEDs, 4 x WAN status LEDs, 1 x Power LED, 2 x 2.4G and 5G WiFi LEDs
• Operating temperature: -40 °C - 75 °C
• Enclosure: Aluminum enclosure, DIN-rail (can be mounted on both sides), flat surface mounting
• Dimensions (L x H x D): 132 x 44.2 x 95.1 mm
• Weight: 533 g

Software

• Operating system: RutOS (OpenWrt-based Linux OS)
• Mobile features: Multiple PDNs, Auto APN, Band lock, SIM switching, Operator black/white list, Data/SMS limits
• Network features: Routing, Failover, Firewall, DHCP, DDNS, Load balancing, VoIP passthrough, Connection monitoring
• Monitoring and management: WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS
• VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier
• Cloud solutions: RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• Hotspot: External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
• GNSS: NMEA output, AVL, Geofencing

Package includes

• RUTX50 router
• 18 W power adapter
• 4 x Mobile antennas (rotatable, SMA male)
• 2 x WiFi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
• 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
• Ethernet cable (1.5 m)
• SIM adapter kit
• QSG (Quick Start Guide)
• Packaging box
