Now for Embedded World fair: the MHO934 model (ovh 1027,85€), AFG50 two-channel 50MHz function generator option (ovh 412,90€) and BAG-800 carrying case (ovh 86,60€) together for only 925,06€ (VAT 25.5%)! Offer valid 09.03.2026 – 13.03.2026.

Features

• Analog bandwidth: 350 MHz (50 Ω, -3 dB)
• 4 analog channels
• 16 digital channels (requires logic analyzer head)
• Vertical resolution: 12 bits
• Rise time (50 Ω, 10–90%): typically 1 ns
• Real-time sampling rate: up to 4 GSa/s (1 channel), 2 GSa/s (2 channels), 1 GSa/s (all channels)
• Standard memory depth: 100 Mpts (1 channel), 50 Mpts (2 channels), 25 Mpts (4 channels)
• Optional memory depth: 500 Mpts (1 channel), 250 Mpts (2 channels), 125 Mpts (4 channels)
• Waveform capture rate: up to 1 000 000 wfms/s (fast record mode), 30 000 wfms/s (vector mode)
• Hardware real-time waveform recording and playback: up to 500 000 frames
• Input impedance: 50 Ω ±1% or 1 MΩ ±1%
• Optional function/arbitrary waveform generator: 2 channels, 100 MHz or 50 MHz, 1 GSa/s
• Bode plot function: sweep range 10 Hz – 30 MHz
• 7-inch capacitive multi-touch display, resolution 1024 × 600
• Interfaces: HDMI, LAN (100M), USB 2.0 Host and Device
• Programming support: SCPI commands

Rigol MHO900 Series Oscilloscopes Comparison Table

Delivery includes

• MHO934 oscilloscope
• Power supply
• Grounding cable
• USB cable
• 4 x passive probes (PVP2350, 350 MHz)
