Features

• Based on RIGOL's new, self-developed Centaurus technology platform
• 12-bit resolution across all series (16-bit in high-resolution mode)
• Max. 1 GHz bandwidth, 8 analog channels and 1 external trigger channel
• MHO models include 16 digital channels as standard configuration (requires purchase of a logic analyzer probe)
• Real-time sampling rate: up to 4 GSa/s
• Maximum memory depth 500 Mpts
• Vertical sensitivity up to 100 μV/div
• Maximum waveform capture rate 1 000 000 wfms/s in fast capture mode
• Arbitrary Waveform/Function Generator (AFG) (only MHO5054 and MHO5104), power analysis, histogram and digital signal analysis (MHO series only), Bode plot (only MHO5054 and MHO5104) and protocol decode
• Search and navigate function helps users quickly find signals with anomalies and locate them precisely
• 256-level intensity grading display with digital real-time persistence
• 10.1-inch 1280*800 high-resolution touchscreen
• Standard configuration of USB Device, USB Host, LAN and HDMI interfaces across all series
• Battery-powered, convenient to charge anywhere, providing excellent measurement portability
• Online update capability
• Standard configuration of an optical encoder control knob across all series to improve device lifespan

Rigol DHO5000 Series Oscilloscopes Comparison Table

Delivery includes

• DHO5058 oscilloscope
• Eight high impedance RP3500A probes
• Power cord
• USB cable

Note! Bandwidth upgrade option available from 500 MHz to 1 GHz (DHO5004-BWU5T10).
