Features

• Pluggable PCB connector, plug (female)
• Screw connection for secure, maintenance-free wiring
• 4 poles, single row
• Suitable for industrial and automation applications
• Locking latches ensure the connection
• Green housing, industrial standard

Technical data

• Manufacturer: Dinkle
• Series: 3ESDV
• Number of poles: 4
• Pitch: 7,62 mm
• Rated current: 18 A (IEC), 15 A (UL)
• Rated voltage: 800 V (IEC), 300 V (UL)
• Conductor cross-section: 0,2–2,5 mm² / AWG 12–30
• Connection type: Screw connection
• Operating temperature: −40 °C … +120 °C
• Material: PA, UL94 V-0
• Contact plating: Tin
• RoHS: Compatible

Delivery

• Supplied as individual pieces
• Compatible with Dinkle 3ESDV housings of the same series
