General

• processor: BCM2835 with VC4
• clock frequency: 1GHz
• memory: 512MB RAM

• WiFi: 802.11 b/g/n
• Bluetooth 4.1
• Bluetooth Low Energy (BLE)

• microSD card slot

Connectors

• Mini HDMI
• Micro USB On-The-Go port
• Micro USB for power. Power supply recommended 5V at least 1A
• GPIO pins: 40 pcs (pre-soldered straight pin header)
• connector for composite video
• connector for reset
• CSI camera connector: (narrow connector)

Other

• Dimensions: 66 x 30,5 x 5,0mm
• Weight: 9g

Note! For Raspberry Pi Zero v1.3 and Raspberry Pi Zero W users:
The Raspberry Pi camera package includes an FFC cable, but the included FFC cable does not fit the Zero.

An FFC cable for Raspberry Pi Zero is available separately.
Partcon product code is: RPI FFC ZERO CAMERA

The case includes an FFC cable suitable for Raspberry Pi Zero:
Partcon product code is: RPI ZERO W CASE
