Note! Suitable for use with Raspberry Pi 5, but requires the RPI SC1128 adapter cable (see below)

Features

• Image sensor:
  • SONY IMX477R stacked, back-illuminated sensor
  • 12.3 Megapixels
  • 7.9mm sensor diagonal
  • 1.55um x 1.55um pixel size
• Output: RAW12/10/8, COMP8
• Lens back focal length: 2.6mm - 11.8mm
• Lens standards: M12-mount
• Lens sensor format: 1/2.3" (7.9mm) or larger
• No focus lens included, but it is REQUIRED to purchase separately
• IR filter: integrated
• Ribbon cable/FFC length: 200mm
• Tripod mount: 1/4" - 20
• Compliance:
  • FCC 47 CFR Part 15, Subpart B, Class B Digital Device
  • Electromagnetic Compatibility Directive (EMC) 2014/30/EU
  • Restriction of Hazardous Substances Directive (RoHS) 2011/65/EU
• Connect to the Raspberry Pi board via the supplied FFC/Ribbon cable
• Dimensions: 38mm x 38mm x 19.18mm
