UM-SBC-214 Rackmount Kit is a durable, professional solution that allows you to mount up to eight Raspberry Pis or similar single-board computers (SBCs) in a 19" server rack. The 2.00U height provides ample space for accessories such as cooling and power management solutions. An excellent choice for high-density server and testing environments.

Features

• Compatibility: Raspberry Pi 2B, 3B, 3B+, 4B, 5 and other Raspi-format SBCs
• Capacity: Slots for eight devices in a single 2.00U rack enclosure
• Mounting: Each device is secured with four M2.5 screws (included)
• Extra space: The generous height allows a variety of expansions such as PoE HATs, UPS modules and active cooling solutions
• Cable management: Includes cable ties for neat and organized cabling

Technical specifications

• Rack size: 19", 2.00U
• Dimensions (L × H × D): 482.6 × 87.8 × 310 mm
• Material: Steel
• Color: Front panel: white aluminum (RAL 9006), chassis panels: black (RAL 9005)
• Fan compatibility: 4x 40×40 mm (mounting hole spacing 32×32 mm), mounted with two screws per fan
• Telescopic rails (optional): 200 mm pull-out rails to facilitate maintenance

Package contents

• 1x UM-SBC-214 Rackmount Kit
• 4x Rack mounting screw sets
• 10x Cable tie 100 mm
• 5x Cable tie 300 mm
• 80x M2.5 mm screws for securing devices
• 1x Product datasheet
• 1x Installation manual

Note!

• Computers (e.g. Raspberry Pi) are not included

Links

• Product datasheet (PDF)
