Features

• Data logging via USB using the DMM Tool software
• TrueRMS
• LowZ low impedance measurement mode
• Min, max, hold and duty functions
• Measurement of small currents (mA and µA)
• Measurement of small voltages (mV)
• Functions: DC V, AC V, DC A, AC A, LowZ AC V, Resistance, Capacitance, Frequency, Temperature, diode test, continuity test

Technical specifications

• Voltage max.: 1000 V AC/DC
• Voltage mV max.: 600mV AC/DC
• Current max.: 20 A AC/DC
• Current mA max.: 600mA AC/DC
• Current µA max.: 6000µA AC/DC
• Resistance max.: 60 MΩ
• Temperature: -20 °C...1000 °C
• Capacitance max.: 6mF
• Diode test voltage: 3.3 V DC
• Safety rating: EN 61010-1; CAT III 1000 V / CAT IV 600 V
• Battery: 9V

Download the DMM Tool software from this link

Included in delivery: meter, storage case, test leads, temperature probe, USB cable, battery, user manual
