OWON® OW16A is a digital multimeter. Large backlit LCD with bar graph. True RMS (TRMS) measurement ensures more accurate results for AC voltage and current measurements compared to conventional multimeters. Auto power-off to extend battery life. Can measure AC/DC voltage and current, resistance, capacitance, frequency, temperature, diode test and audible continuity test.

Technical specifications

• LCD display 3 5/6 digits (5999)
• measurement interval: 1/3 s
• DC voltage measurement: 0.1 mV - 1000 V, ±(0.5%+2 digits)
• AC voltage measurement: 0.1 mV - 750 V, ±(0.8%+2 digits)
• ACV measurement = displays the frequency of the AC voltage
• DC current measurement: 0.1 μA - 10 A, ±(0.8%+2 digits)
• AC current measurement: 0.1 μA - 10 A, ±(1.0%+2 digits)
• resistance: 0.1 Ω - 60 MΩ, ±(0.8%+2 digits)
• capacitance: 60 nF - 60 mF, ±(2%+3 digits)
• frequency: 0.001 Hz - 9.999 MHz, ±(0.8%+2 digits)
• PWM duty cycle: 0.1% - 99.9%, ±(1.2%+3 digits)
• temperature: -50...+400 °C, ±(2.5% of reading +3 digits)
• continuity test: beeps
• protection class: CAT II 1000V, CAT III 600V
• batteries: 2x 1.5V AA (not included)

Delivery includes: OW16A multimeter, K-type thermocouple, English user manual.

Finnish user manual available on request.

Links

• Quick Guide for OW16 Series Digital Multimeter
• User Manual for OW16 Series Digital Multimeter
