Features:

• IEEE 802.3af/at compliant PoE and Ethernet combo ports
• Up to 30 W output per PoE port
• Intelligent power consumption detection and classification
• IP30-rated metal housing
• -10 to 60°C operating temperature range

Specifications:

• IEEE 802.3 for 10BaseT
• IEEE 802.3af/at for PoE/PoE+ output
• IEEE 802.3x for flow control
• IEEE 802.3u for 100BaseT(X)

Standards and certifications:

• Safety

   UL 508

• EMC

           EN 55032/24

• EMI

  CISPR 32, FCC Part 15B Class A

• EMS

  IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
  IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
  IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
  IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
  IEC 61000-4-6 CS: 10 V
  IEC 61000-4-8 PFMF

Input voltage:

• 12/24/48 VDC, Redundant dual inputs
