The total power of the master + slave switch is max. 3680 W (16 A). The slave's maximum power is 2300 W (10 A). Master-load sensitivity is adjustable.

Technical specifications

• Operating voltage: 230 V/AC / 50 Hz
• Maximum current: 16 A, 3680 W (total for master and slave devices), with the maximum power for the "Slave" device being 2300 W (10 A). For example, if the "master" connection requires 9 A, a "slave" load of up to 7 A can be connected.
• Adjustable switch-off power: approx. 5–60 W
• Operating temperature range: 0°C up to +50°C
• "Slave" switching function: triac max. 2300 W (10 A)
• "Slave" minimum load: approx. 10 W (0.05 A)
• Own power consumption: under 0.2 W
• Operation indicator: 2-color LED, green – module ready for use, red – slave device active.
• Connections: flat 6.3 mm connectors
• Dimensions: approx. 87 x 60 x 33 mm
