BR-1225A lithium battery 3V (coin cell)

BR-1225A is a high-temperature resistant lithium coin cell (poly-carbon monofluoride). It is especially suitable for industrial backup power applications and long-term memory backups.

Technical specifications

• Type: Lithium battery (non-rechargeable)
• Nominal voltage: 3 V
• Capacity: approx. 48 mAh
• Diameter: 12.5 mm
• Height: 2.5 mm
• Weight: approx. 0.8 g
• Continuous discharge current: ~30 µA
• Operating temperature: -40 °C … +125 °C

Features

• Very good temperature resistance
• Low self-discharge
• Long service life in backup power applications
• Stable voltage throughout discharge

Applications

• Memory backup (PLC, measuring instruments)
• Industrial automation
• Electric and water meters
• Automotive electronics

Note: BR-series batteries are designed for low-current applications. Not suitable for loads requiring high current.
