Measuring range

AC 0.1 - 130Arms (185Apeak)

DC 0 - ±180A

Output voltage

AC 10mV/A

DC 10mV/A

Accuracy

±1.2%rdg±0.4mV (50/60Hz)
±2.5%rdg±0.4mV (40 - 1kHz)

±1.2%rdg±0.4mV (*)

Low battery warning

2.2V±0.2V or less - Red LED flash
(1.9V±0.2V - Automatically power off)

Conductor size

Max. Ø12mm

Withstand voltage

AC 3540V (RMS 50/60Hz) for 5 sec.

Operating temperature & humidity range

-10 to 55ºC, relative humidity 85% or less (no condensation)

Output impedance

Approx. 10Ω or less

Applicable standards

IEC 61010-1 CAT III 300V Pollution degree 2,
IEC 61010-2-032, IEC 61326-1

Power source

DC3V (size AAA alkaline battery LR03×2pcs)
* Continuous use: approx. 40 hours
(Auto power off: approx. 20 minutes)

Cord length

Approx. 1,200mm

Output connector

Φ4mm banana plug

Dimensions

127(L)×42(W)×22(D) mm

Weight

Approx. 140g

Accessories

Soft case, LR03×2, Instruction manual
