• measurements for both single-phase and three-phase networks
• relatively large jaw Ø 55mm for conductors
• versatile TrueRMS power, voltage and current measurements
• 1000 A rms, 1000 V rms, 1000 kW, harmonics 1-30
• separate functions MAX/MIN/AVG/PEAK
• measurements: 1P2W, 1P3W, 3P3W, 3P4W
• CAT IV 600 V / CAT III 1000 V
• batteries 2x AA (LR6)

Measured quantities

• voltage
• current
• frequency
• active power
• reactive power
• apparent power
• power factor
• phase angle
• harmonics (THD-F, THD-R)
• rotation direction

Delivery

Included in delivery: 2062 clamp meter, 7290 test leads, 9198 soft case, batteries, English user manual
