PRODUCT DETAILS

A soil moisture sensor is one that detects the volumetric water content of the soil. The Grove - Capacitive Soil Moisture Sensor (Corrosion Resistant) is a soil moisture sensor based on capacitance changes. Compared with resistive sensors, capacitive sensors do not require direct exposure of the metal electrodes, which can significantly reduce the erosion of the electrodes. Hence, we call it Corrosion Resistant.

It is important to note that this sensor can only qualitatively test the humidity of the soil and cannot measure quantitatively. When the humidity of the soil rises, the value of the output decreases; conversely, when the humidity decreases, the output value becomes higher.

Feature

• Capacitive Style
• Corrosion Resistant
• Built-in Amplifier

Typical Applications

• Soil moisture detection
• Automatic watering of plants

Links

• Grove - Capacitive Moisture Sensor (Corrosion Resistant)
• Grove Selection Guide

• Grove - Capacitive Moisture Sensor (Corrosion Resistant) Eagle Files
• NE555DR Datasheet
• PDF Format Wiki
