Electrolytic Capacitor, 9100 µF, 200 V

out of stock

SKU#: ALF70G912KP200

Electrolytic Capacitor, 9100 µF, 200 V

Kemet

Electrolytic Capacitor, 9100 µF, 200 V

out of stock

SKU#: ALF70G912KP200

44,00 €

Order by Request

Add a comment about the product to my order

Fast delivery from Finland

Reliable and versatile delivery options

Payment options

Invoice, online payments, cards, MobilePay

Product Description

Capacitance: 9100 µF
Rated voltage: 200 VDC
Tolerance: ±20 %
Type: Aluminum electrolytic, snap-in
Series: ALF70
ESR: 29,47 mΩ @ 100 Hz
Ripple current:
- Low frequency (100 Hz): 11,39 A
- High frequency (10 kHz): 16,89 A
Impedance: 20 mΩ
Leakage current: 6 mA
Lifetime: 18 000 hours @ 85 °C
Operating temperature: −40 °C – +85 °C
Mounting type: Through-hole, snap-in (5-pin)
Dimensions:
- Diameter: 50 mm
- Height: 105 mm
- Lead spacing: 25 mm

Product Information

Availability Order by Request
Manufacturer Kemet
Product path Home Components Passive Components Capacitors ELKOT 85°C Electrolytic Capacitor, 9100 µF, 200 V
SKU ALF70G912KP200
