Description:

The CrowPanel ESP32 Display 1,28 tuuman pyöreä näyttö uses ESP32-C3 as the main controller and is equipped with a 32-bit single-core chip with a maximum clock of 160 MHz. It supports 2.4G WiFi and BLE low-power Bluetooth, suitable for IoT, smart home and other applications.
This 1,28 tuuman pyöreän näytön has a resolution of 240*240, IPS display and 178° viewing angle, allowing more vivid and realistic images from any angle. It is equipped with a capacitive touchscreen and is sensitive; it has dedicated buttons, RESET and BOOT buttons, and a UART serial port allows firmware updates. It supports Arduino IDE, Espressif IDF, Lua RTOS, Home Assistant/PlatformIO/Micropython and the LVGL library. You can design the user interface yourself, making it an ideal platform for DIY projects.

Features:

• 1,28 tuuman IPS round display, resolution 240×240
• Rotary encoder (requires separate knob)
• 32-bit RISC-V single-core processor, up to 160 MHz
• 384 KB ROM
• 400 KB SRAM (16 KB for cache)
• 8 KB SRAM in RTC
• Type-C connector, battery connection
• Wireless: 2.4 GHz Wi-Fi (802.11 b/g/n), BLE 5.0
• power consumption about 80mA
• Operating temperature -10 °C – 65 °C
• Supports Arduino IDE, Espressif IDF, Lua RTOS, Esphome-home assistant/PlatformIO/Micro python and the LVGL library.
• Comprehensive datasheet at this link

Package includes:

• ESP32 display – 1,28 tuuman round display
• USB A/C cable

Requires a fixed 5V power supply, no PD-trigger
