Easy-to-use 7-segment driver for common-cathode (CC) displays. Each segment output requires only suitable series resistors.

• Low logic circuit power dissipation
• High current sourcing outputs (up to 25 mA)
• Latch storage of code
• Blanking input
• Lamp test provision
• Readout blanking on all illegal input combinations
• Lamp intensity modulation capability
• Time share (multiplexing) facility
