Overview

• MCU-controlled temperature calibration with a PID system.
• The heater uses a low-voltage AC power supply to ensure antistatic and leak-free operation, no interference.
• Smooth temperature setting 200～480 ℃.
• Legerity-handle, suitable for long-term use.
• Wide selection of T900 series tips (click here)

Features

• Simple temperature setting using the adjustment knob
• Mechanical lock for temperature control
• ℃/℉ scale
• Automatic sleep mode
• LED indicator shows the device status

1. The LED indicator stays steadily lit, which means this device is heating up.
2. The LED indicator is off means that this device is not heating.
3. The LED indicator becomes lighter from dark and then darker in a loop, meaning this device is at stable temperature.
4. The LED indicator flashes meaning this device is entering sleep or standby mode.

Specifications

• Power: 60W
• Supply voltage: 110VAC/220VAC ±10% 50Hz/60Hz
• Temperature control: 200℃~480℃/392℉~896℉
• Accuracy: ±2℃ at idle temperature
• Tip-to-ground resistance: <2Ω
• Tip-to-ground voltage potential: <2mV

Package contents

• Atten AT-969 soldering station, soldering handle AT-AP-65, standard tip T900-B
• Soldering stand with sponge
• Mains lead
• English manual

Note! Check our tip selection here.
