Arduino USB-C Hub (8 in 1) expands the connectivity of the Arduino UNO Q and other compatible Arduino boards from a single USB-C port. The hub adds display, network, USB and storage connections as well as USB-C power delivery passthrough.

The USB-C Hub provides eight available ports, allowing the Arduino UNO Q to be equipped with an HDMI display, wired network connection, multiple USB devices and SD and TF memory cards. The solution is suitable for embedded computers, media projects and development environments.

• 8-in-1 solution: Eight connections from one USB-C port.
• HDMI display connection: Supports external displays up to 4K @ 30 Hz resolution.
• Wired network: RJ45 Ethernet port at 100 Mbps.
• Multiple USB ports: USB-C, USB-A 2.0 and USB-A 3.0 connectors.
• Memory card support: SD and TF card readers.
• Power delivery passthrough: USB-C Power Delivery up to 65 W.

Specifications

• Product name: Arduino USB-C Hub (8 in 1)
• USB-C Power Delivery: up to 65 W power delivery passthrough
• USB-C data port: 480 Mbps
• USB-A 2.0: 480 Mbps
• USB-A 3.0: 5 Gbps
• HDMI output: up to 4K @ 30 Hz
• Ethernet: RJ45, 100 Mbps
• SD card reader: USB 2.0 interface
• TF card reader: supports microSD cards
• Compatibility: Arduino UNO Q and other compatible Arduino boards

Package includes

• Arduino USB-C Hub (8 in 1)
