ADJUSTABLE SMPS 270W 12VDC 20A

Temporarily out of stock

SKU#: MAS-8921-12V

ADJUSTABLE SMPS 270W 12VDC 20A

ADJUSTABLE SMPS 270W 12VDC 20A

Temporarily out of stock

SKU#: MAS-8921-12V

288,83 €

Temporarily out of stock

Add a comment about the product to my order

Fast delivery from Finland

Reliable and versatile delivery options

Payment options

Invoice, online payments, cards, MobilePay

Product Description

ADJUSTABLE SWITCH-MODE POWER SUPPLY 270W 12VDC 20A

input voltage range: 230VAC 2,5A 50/60Hz (190-264VAC)
output voltage range: 12VDC 20A (11,5-15,5VDC)
output voltage is adjusted with a trimmer inside the enclosure
output power: max. 270W
short-circuit, thermal, over-/under-voltage protections
switching frequency: 67kHz (20mV pp-ripple)
efficiency: 86%
metal enclosure dimensions: L 148 x W 210 x H 58 mm
mains cable length: 1,8 m
output has 4 pcs 6,3 mm spade terminals (mate connectors included)

Product Information

Availability Temporarily out of stock
Manufacturer Mascot
EAN 7057070022015
Product path Home Power Supplies Chopper Power Supplies Voltage Adjustable Switching Power Supplies ADJUSTABLE SMPS 270W 12VDC 20A
SKU MAS-8921-12V
Attributes
- Color musta
- Manufacturer's model 8921
- Click for more details http://www.cps.fi/Datasivu/Mascot/8921.pdf
- Dimensions 148 x 210 x 58 mm
