Adafruit ISM330DHCX - 6 DoF IMU ACCELEROMETER STEMMA QT / Qwiic

Name: Adafruit ISM330DHCX - 6 DoF IMU ACCELEROMETER STEMMA QT / Qwiic
Brand: Adafruit
SKU: ADA4502
Price: 34.75 EUR
Availability: InStock

In stock under 5 pcs

SKU#: ADA4502

Adafruit ISM330DHCX - 6 DoF IMU ACCELEROMETER STEMMA QT / Qwiic

Adafruit ISM330DHCX - 6 DoF IMU ACCELEROMETER STEMMA QT / Qwiic

In stock under 5 pcs

SKU#: ADA4502

Adafruit ISM330DHCX is a versatile 6 DoF (Degrees of Freedom) IMU sensor that combines a three-axis accelerometer and gyroscope into one compact module. It is ideal for motion tracking, stabilization, robotics and measuring sports data. STEMMA QT compatible.

34,75 €

In stock

Add a comment about the product

Fast delivery from Finland

Reliable and versatile delivery options

Payment options

Invoice, online payments, cards, MobilePay

Product Description

ISM330DHCX provides high-performance accelerometer and gyroscope sensors in a very small package. It operates over I2C or SPI and is compatible with the STEMMA QT / Qwiic system, making it easy to connect without soldering. The module has a wide operating voltage range of 3,3–5,5 V, so it is suitable for most microcontroller projects.

Technical specifications

Operating voltage: 3,3–5,5 V
Accelerometer: ±2/±4/±8/±16 g
Gyroscope: ±125/±245/±500/±1000/±2000 dps
Interface: I2C or SPI
STEMMA QT / Qwiic compatible connector

Package includes

1 × Adafruit ISM330DHCX - 6 DoF IMU - Accelerometer and Gyroscope Breakout

Link

Adafruit product page
